Technical Specifications
Manufactured 304 stainless steel material.
The product has internal chassis from stainless profile.
Special mechanical devices are designed as durable to malfunctions
It has horizontal brushes that clean the soles of the boots.
The brushes are activated automatically
It is practical to remove and install the brushes.
Hand disinfectant is sprayed with photocell system.
It sprays on 3-5ml disinfectant liquid to both hands at once which includes alcohol in
Hand disinfectant section has double hand receptacles.
Turnstile system does not let unless disinfection of both hand of the staff finished.
Hygienic mat is available.
Stairs on entrance and exit.
It has a barrier system which makes personnel pass in order and obligatory.
Usage
This device has been designed with the aim of forcing the personnel to pass through disinfecting their hands and the soles of their shoes. It is designed as a platform. Compatible with modular products. In the sink, hands are washed with liquid soap and cleaned and dried with paper towels and used paper is thrown into the trash. As the personnel passes through the brushed section and the disinfectant pool, the bottom surface of their shoes is disinfected. Hygienic mats take the excess of disinfectant liquid that is transmitted to the shoes. When you put both hands into the hand sanitizer container, the motion sensor will automatically switch on the device and spray 3-5 ml of alcohol-based disinfectant on the top and bottom of the hands. Then the device opens the tourniquet to allow personnel to pass. A warning tone will sound to indicate that a pass is granted. Staff must insert both hands into the chamber; otherwise, the device will not operate and personnel will not be allowed to pass. After the hands are disinfected, staff must pass through the tourniquet within 15 seconds, otherwise the right of passage will be canceled. The beep will silence. The direction of transition to the turnstile is indicated by green colored leds.
Maintenance
Clean your device regularly with a damp cloth or stainless steel surface polishers. Do not allow dirt or debris to block the drain hole of the sink. Remove dirt and debris from the hand disinfectant container to prevent the drain hole from clogging. Check the disinfectant container regularly and replace it when it is empty. Clean the hygienic mat, pan and shoe hygiene pool regularly.
Accessory
This product can be equipped with a timed automatic filling and discharging system for the foot disinfectant pool. Liquid soap dispensers and paper dispensers on the device can be replaced if desired. Modular equipment can be connected. AYG-02-120 Automatic horizontal brushed foot disinfectant module, AYG-02-130 Automatic vertical brushed foot disinfectant module, AYG-02-140 Horizontal and vertical brushed boat washing module.
