Specifications
Control / Operating Voltage | 24 V DC ± %20 |
Power Consumption | 30 W |
Pass Blocking | With controlled rotating tripod arms placed spaced 120° |
Tripod Locking | With 24 V DC selenoids; locking takes place while selenoids are towed.(In case of panic, the system power is cut off and the tourniquet becomes open for passage in both directions.) |
Transition Direction Control | Two-way input / output independent control |
Location Detection | Tripod position detection with two microsvices |
Motion Control | After the half-turn, the arrival to the next position is achieved by automatic and softening thanks to the spring and hydraulic shock absorber structure. |
Ground Connection | Özel yer bağlantı kaidesi ile kolay ve basit montaj |
Operating Temperature | - 20° C - + 70° C |
Transition Warning | One (↑/X ) illuminated indicator in each direction |
Dimensions | 300 x 810 x 1034 mm |
Weight | 50 kg |
Additional Accessories | Falling arm, remote control unit, button unit |
